These advance counting scales can weigh even the lightest parts with an accuracy of over 99%, minimizing the operator error often found when hand counting. The counting scale range is tough enough to stand up to any industrial environment and can stand up to overloading and shock loading while counting quickly and accurately. With 20 direct memories to store, Auto power off, Built In rechargeable battery and check weighing function makes this and ideal partner in all stores and counting applications. Standard Features of Counting Scales
Technical Specifications of Industrial Counting ScalesModel: CK-430 Description: Digital Weighing & Counting Table Top Scale Physical Dimension: 320 x 335 x 105 mm (±10 mm) Net Weight: Approx 3.0 Kg (Without Battery) Weight Sensor: Aluminum Load Cell IP65 Processor: 8 Bit Arm processor Key Board: 44 Keys Display Type: LCD with Moon Backlight & Symbols No. Of Display Window: Single Window with 3 levels of readings for Weight, Piece Weight & Total Count Display Size: 12.5mm Display size for each level with Moon Backlight Repeatability: ±1d Linearity: ± 1d At Half Load & ± 2d At Full Load Creep: ± 2d (for 3 minutes at full capacity) Calibration Method: External Calibration Software Based Power Connector: 2 Pin Mains Cord (5A) Power Supply: 160 V ~ 170 V to 240 V (AC) Frequency: 50 Hz Power Consumption: < 2 Watt Operating Temperature: 0oC to 50oC Operating Humidity: 95% RH Max (Non-Condensing) Battery Capacity: 6V / 4.5 AH Over-load: 100% Of Scale Capacity +9e Safe-load: 150% Of Scale Capacity Stabalisation Time: < 3s Internal Resolution: 20 Bit ADC - 10,00,000+ Counts Model Approval No.: IND/09/2017/58 Related Products/ServicesWe offer solutions for any kind of Weighing Application - Be it simple Weighing Scale, counting of parts, Bulk Weigh, Jewellery Scales, Dynamic Weighing, taking Weight of your new born Baby or Weighing a 120 Ton Fully Loaded Truck by Electronic Weighbridge and Calibration Services to International Standards. We have an Unparalleled Weighing Range From 0.01 Mg To 120 Tons for use in varied applications in the fields of Quality Control, Production, Logistics, Retail etc. Products / ServicesHigh Precision Jewellery Weighing Scale, Industrial Scales, Table top Simple Weighing, Splash Proof Scales, Electronic Weighbridge, Truck Weigh Bridge, Counting Cum Weighing Scale, Check Weighing Scale, Price Computing Scale, Mechanical Personal Scale, Body Fat / Hydrating Scales, Mechanical Kitchen Scale Nature of Business Manufacturers Contact Person Mr. Manager Contact UsE. G. Kantawalla Pvt Ltd.Next to Prakash Memorial School, Upper Kharadi Road, Ubale Nagar, WagholiPune, Maharashtra, 412207, India Related Products/Services in PuneRecently Added Products in Pune, MaharashtraRecently Registered Companies in Pune, Maharashtra |
