500 Kg Load Cell

500 Kg Load Cell


500 Kg Load Cell

x
{{image.image_title}}
Prev
Next
Item Code: JMS-410
Capacity: 200 Kg, 300 Kg, 500 Kg, 750 Kg, 1000 Kg
Material: Tool Steel load cell, also available in SS
Type: Single Point Load Cell, Low Profile Load Cell
Cost effective, Easy to install and use
Made in India, Stock Available


Send Inquiry




Features of Single Point 500 Kg Load Cell

  • Platform sizes: 200 x 200mm up to 1200mm x 1200mm
  • Capacities: 300g to 2000kg.
  • Highly accurate and reliable
  • Cost effective, Easy to install and use
  • Available with various certifications for use in different industries (OIML, NTEP, ATEX, FM)
  • Many of the single point load cells we can offer are protection rated, either IP67, IP66 or IP65.
  • Material: Tool steel Construction for Harsh application, also available in Stainless Steel
  • Minimum error for Off-Centre loading
  • Low profile
  • Usage: Suitable for hygienic applications like Food, Dairy & Pharmaceutical Industries, Chemical Plant
  • Single point load cell is the most popular type of load cell in industry.
  • Its main feature is its ability to accurately weigh in applications in which products may be placed anywhere in a relatively large platform area
  • A single point load cell can accurately weigh an area much larger than its footprint. This ability to use only one load cell instead of four makes the single point load cell a very economical solution for dozens of applications.


Technical Specifications of Single Point Load Cell

PrecisionC2 / C3
Excitation Voltage (V)10 to 15 (DC)
Composition Error0.03 / 0.02
Excitation Voltage (V)10 to 15 (DC) ≥ 20000(100 VDC)
Rated Output (mv/v)2.0 ± 10%
Compensated temp. Range-10 to 40 °C
Non-Linearity (%FS)0.025
Use Temp. Range-20 to 60 °C
Hysteresis (%FS)0.01
Temp. Effect on Zero 0.0020 %FS/10°C
Repeatability0.02 / 0.01 (%FS)
Temp. Effect on Span 0.0015 (%FS/10°C)
Creep (%FS/30min)0.03 / 0.02
Safe Overload (%FS)150% of rated capacity
Zero Balance (%FS)± 1.0
Ultimate Overload (%FS)250% of rated capacity
Input Resistance (Ω)400 ± 10
Defend GradeIP65
Output Resistance (Ω)350 ± 2
Cable6 mm, 2.5 mtr
