Single Point Bending Beam Load Cell

Single Point Bending Beam Load Cell


Single Point Bending Beam Load Cell

x
{{image.image_title}}
Prev
Next
Material: Alloy Steel, Nickel Plated
Load Cell Type: Single Point Bending Beam
Load Cell Capacity: 5 kg to 500 Kg
Ingress Protection: IP68
Accuracy: C3
Business Type: Manufacturers, Wholesale suppliers of Load Cell in Delhi


Send Inquiry




Features of Single Point Bending Beam Load Cell

MaterialAlloy Steel, Nickel Plated
Load Cell TypeSingle Point Bending Beam
Ingress ProtectionIP68
ProtectionHermetically welded
Type:Tension or compression type load cell
UsageSuitable for Belt Scales, Hooper Scales, electronic weighing scales
Accuracy ClassC3
Capacity Available5 kg to 500 Kg
Safe Overload150% of rated Capacity
Ultimate Overload300% of rated Capacity
Compensated Temperature-10 to 40 °C
Operating Temperature Range-35 to 70 °C
Combined Error (%FS)±0.020
Recommended Excitation Voltage5 to 12 V DC
Max Excitation Voltage18 V DC
Creep (%FS/30 min)±0.016
Temperature effect on sensitivity (%FS/10°C)±0.011
Temperature effect on zero (%FS/10°C)±0.015
Zero Balance (%FS)±1.0
Output Sensitivity (=FS)2.0 ±0.02 mV/V
Input Terminal Resistance (Ohm)460 ±50
Output Terminal Resistance (Ohm)350 ±3.5
Insulation Impedance (M Ohm)≥5000 (50VDC)
Load Cell Cable4/6 conductor wires, diameter 5±0.2mm, 3m/6m length,
